Ahmed Sheets and Plates, located in Safat, Kuwait, has earned a solid reputation as a reliable manufacturer and supplier of top-notch Super Duplex Steel S32750 Sheets and Plates. They cater to a variety of industries that demand materials with outstanding mechanical strength and resistance to corrosion. Known for their dedication to precision, durability, and adherence to international quality standards, this company provides products designed to endure even the harshest environments. Their Super Duplex Steel S32750 Sheets and Plates are particularly recognized for their exceptional performance in marine, chemical, and high-pressure applications. With a wealth of manufacturing expertise and rigorous quality control practices, Ahmed Sheets and Plates guarantees dependable, long-lasting products that adapt to the changing needs of industrial clients.
The Super Duplex Steel S32750 Sheets and Plates are crafted from a blend of chromium, nickel, molybdenum, and nitrogen, resulting in a well-balanced austenitic-ferritic microstructure. This alloy boasts impressive tensile and yield strength, remarkable resistance to pitting and crevice corrosion, and excellent resistance to stress corrosion cracking. Its superior mechanical properties enable it to function effectively under high pressure and temperature. Additionally, the material provides good toughness, weldability, and fatigue strength. These features make S32750 an ideal choice for environments that require robust structural integrity and long-lasting corrosion resistance.
| Standard Specification : | Super Duplex Fittings |
| Coating Fitting Faces : | Cold and Hot Dip Galvanized, Zinc Plated, Yellow Transparent, Oil Black Paint, Anti-rust Paint |
| Thickness: | View Our Thickness: Schedule 5S, SCH10, SCH20, SCH10, SCH20, SCH30, SCHTD, SCH40, SCH60, XS, SCH80, SCH100, SCH120, SCH140, SCH160. |
| Rating Pressure: | Pressure Rating Of: 3000 LBS, 6000 LBS, 9000 LBS |
| Check Sizes: | (SMLS UPTO 24”) 1/2” TO 36” (Buttweld 8” TO 36” ) |
| Standard: | MSS-SP-43 Type B Fittings, ANSI B16.28 Fittings, JIS B2312 Fittings, JIS B2313 Fittings, ANSI B16.9 Fittings, MSS-SP-43 Type A Fittings, MSS-SP-43 Type b Fittings |
| Dimensions Class: | 2000#, 3000#, 6000#, 9000# |
| Application: | Chemical Industry Water Pipeline Industry Nuclear Power Plant Natural Gas Industry Fabrication Industry Oil And Gas Industry |
| Fitting Machining Equipment: | Press machine, electric bevelling machine, Bending machine, Pushing Machine, Sand-blasting machine etc |
| Element | C | Mn | Si | P | S | Cr | Ni | Mo | N | Fe |
| Super Duplex Steel Pipe Fittings S32750 | 0.030 max. | 2.00 max. | 1.00 max. | 0.030 max. | 0.020 max. | 21.0 – 23.0 | 4.50 – 6.50 | 2.50 – 3.50 | 0.08 – 0.20 | 63.54 min |
| Element | Density | Melting Point | Tensile Strength | Yield Strength (0.2%Offset) | Elongation |
| Super Duplex Steel Pipe Fittings S32750 | 7.805 | 0.285 | 1420 – 1465 | 2588 – 2669 |
We provide products that come with both mill test certificates and third-party test certificates, ensuring the highest standards of quality and compliance.
Super Duplex Steel Sheet and Plates S32750 offer several key advantages, making them ideal for challenging environments. Their high chromium and molybdenum content provide exceptional resistance to pitting, crevice, and stress corrosion cracking, especially in chloride-rich environments like marine and offshore applications. With superior strength, they offer a high strength-to-weight ratio, ensuring reliability in demanding conditions. The alloy also exhibits excellent weldability, allowing for easy fabrication into complex structures. Additionally, Super Duplex Steel S32750 performs well at elevated temperatures, making it a top choice for industrial and chemical processing sectors.
Yes, we offer custom sizes for Super Duplex Steel Sheet and Plates S32750 to meet specific project needs. Our team at Ahmed Sheets and Plates is dedicated to providing tailored solutions for all your requirements. For more details, contact us at sales@aaronsheetsplates.com.
| Sheet & Plate Surface finish | Gauge (in) | Width (max in) |
|---|---|---|
| 2B – Cold rolled, heat treated, pickled, skin passed Plate | 10–24 | 72* |
| 2D – Cold rolled, heat treated, pickled plate | 12–24 | 60 |
| BA Mexinox only | 18–28 | 48 |
| Polished Sheet (not brushed) | 11–24 | 60 |
| Temper rolled Sheet Mexinox only | 13–29 | 48 |
| Plate Thickness (mm) | Weight (kg/m) | kg/meter (width 1200mm) | kg/meter (width 1500mm) | kg/meter (width 1800mm) | kg/meter (width 2400mm) |
| 3 | 23.55 | 28.3 | 35.3 | 42.4 | 56.5 |
| 4 | 31.4 | 37.7 | 47.1 | 56.5 | 75.4 |
| 5 | 39.25 | 47.1 | 58.9 | 70.7 | 94.2 |
| 6 | 47.1 | 56.5 | 70.7 | 84.8 | 113 |
| 8 | 62.8 | 75.4 | 94.2 | 113 | 150.7 |
| 10 | 78.5 | 94 | 118 | 141 | 188 |
| 12 | 94.2 | 113 | 141 | 170 | 226 |
| 16 | 125.6 | 151 | 188 | 226 | 301 |
| 20 | 157 | 188 | 236 | 283 | 377 |
| 22 | 172.7 | 207 | 259 | 311 | 415 |
| 25 | 196.25 | 236 | 294 | 353 | 471 |
| 28 | 219.8 | 264 | 330 | 396 | 528 |
| 32 | 251.2 | 301 | 377 | 452 | 603 |
| 36 | 282.6 | 339 | 424 | 509 | 678 |
| 40 | 314 | 377 | 471 | 565 | 754 |
| 45 | 353.25 | 424 | 530 | 636 | 848 |
| 50 | 392.5 | 471 | 589 | 707 | 942 |
| 55 | 431.75 | 518 | 648 | 777 | 1036 |
| 60 | 471 | 565 | 707 | 848 | 1130 |
| 65 | 510 | 612 | 765 | 918 | 1224 |
| 70 | 549.5 | 659 | 824 | 989 | 1319 |
| 75 | 588.75 | 707 | 883 | 1060 | 1413 |
| 80 | 628 | 754 | 942 | 1130 | 1507 |
| 90 | 706.5 | 848 | 1060 | 1272 | 1696 |
| 100 | 785 | 942 | 1178 | 1413 | 1884 |
Super Duplex Steel S32750 Sheets and Plates find extensive use in industries that operate in highly corrosive and demanding settings. In the oil and gas sector, they are essential for offshore platforms, subsea pipelines, pressure vessels, and heat exchangers. The chemical and petrochemical industries depend on them for reactors, processing equipment, and storage tanks due to their ability to withstand aggressive chemicals. Desalination plants utilize them for evaporators, brine heaters, and systems handling high-salinity water. Furthermore, S32750 plates are also used in marine engineering, pulp and paper processing, power generation, and structural applications that require high durability.
