Ahmed Sheets and Plates, located in Safat, Kuwait, is a reputable manufacturer and supplier of top-notch EN 9 sheets and plates. Renowned for their precision engineering and reliable product performance, this company provides EN 9 carbon steel materials that adhere to international standards, catering to a diverse array of industrial needs. With a strong focus on durability, accuracy, and timely delivery, Ahmed Sheets and Plates has built a solid reputation among clients looking for dependable steel solutions. Their EN 9 sheets and plates are prized for their exceptional strength, impressive wear resistance, and consistent performance in challenging applications.
EN 9 sheets and plates are made from medium-carbon steel, containing about 0.5% carbon, along with manganese, silicon, and trace elements that enhance toughness and hardness. This unique composition strikes a perfect balance between machinability and strength. Mechanically, EN 9 boasts high tensile strength, remarkable wear resistance, and reliable impact performance. It can also be heat-treated to further boost its hardness and durability. These characteristics make EN 9 ideal for applications that demand abrasion resistance and the ability to endure high mechanical stress.
| Item | Stainless Steel 420 sheet(Hot rolled, cold rolled) | |
| Thickness | 0.01~200mm | |
| Width | 1000mm, 1219mm, 1500mm, 1800mm, 2000mm, 2500mm, 3000mm, 3500mm, etc | |
| Length | 2000mm, 2440mm, 3000mm, 5800mm, 6000mm, etc | |
| Standard | JIS, AISI, ASTM, GB, DIN, EN, etc | |
| Surface | the surface and finish of stainless steel 420 sheet: 2B, 2D, BA, NO.1, NO.4, NO.8, 8K, mirror, checkered, embossed, hair line, sand blast, Brush, etching, etc | |
| Brand: | Indian Origin, European Origin, Japanese Origin, US Origin, Korea Origin, Thailand Origin, Taiwan Origin | |
| Manufacturer: | POSCO, Aperam, Jindal Stainless, DKC Korea, Thyssenkrup, Baosteel, TISCO, Arcelor Mittal, VDM, Nippon Metal, Outokumpu | |
| Package | Shrink-wrapped ,Carton boxes, Wooden pallets, Wooden boxes ,Wooden crates Etc. required. |
Grade | C | Mn | Si | P | S | Cr | Mo | Ni | N | |
420 | 0.15 max | 1 max | 1 max | 0.040 max | 0.03 max | 12.0-14.0 | – | – | – |
| Tempering Temperature (°C) | Tensile Strength (MPa) | Yield Strength 0.2% Proof (MPa) | Elongation (% in 50mm) | Hardness Brinell (HB) | Impact Charpy V (J) | |
| Annealed * | 655 | 345 | 25 | 241 max | – | |
| 204 | 1600 | 1360 | 12 | 444 | 20 | |
| 316 | 1580 | 1365 | 14 | 444 | 19 | |
| 427 | 1620 | 1420 | 10 | 461 | # | |
| 538 | 1305 | 1095 | 15 | 375 | # | |
| 593 | 1035 | 810 | 18 | 302 | 22 | |
| 650 | 895 | 680 | 20 | 262 | 42 |
We provide products that come with both mill test certificates and third-party test certificates, ensuring the highest standards of quality and compliance.
Stainless Steel 420 Sheets and Plates offer excellent advantages, including high hardness and strength, making them ideal for wear-resistant applications. Their Chromium content ensures moderate corrosion resistance, suitable for environments with low exposure to corrosive agents. These sheets excel in machinability and polishing, achieving a smooth, high-quality finish. With outstanding durability and toughness, they are perfect for demanding applications like cutlery, tools, and industrial machinery components. Additionally, their cost-effectiveness and ability to retain sharp edges make them a preferred choice for industries requiring strong and reliable materials.
| STANDARD | WERKSTOFF NR. | UNS | JIS | AFNOR | BS | GOST | EN | |
| SS 420 | 1.4021 | S42000 | SUS 420 | – | – | – | – |
| Grade | Density (kg/m3) | Elastic Modulus (GPa) | Mean Coefficient of Thermal Expansion (μm/m/°C) | Thermal Conductivity (W/m.K) | Specific Heat 0-100°C (J/kg.K) | Electrical Resistivity (nΩ.m) | ||||
| 0-100°C | 0-315°C | 0-538°C | at 100°C | at 500°C | ||||||
| 420 | 7800 | 200 | 10.3 | 10.8 | 11.7 | 24.9 | – | 460 | 550 | |
You’ll find EN 9 sheets and plates widely used across engineering, automotive, and industrial sectors, thanks to their impressive strength and wear resistance. They’re commonly employed in the production of gears, shafts, axles, spindles, crankshafts, and heavy-duty machinery parts that face friction and load. In the automotive industry, EN 9 is a go-to choice for structural components and brake parts that require durability. It’s also utilized in agricultural equipment, mining tools, and general mechanical fabrication. With excellent heat-treatment capabilities, EN 9 steel guarantees a long service life and reliable performance in demanding, high-stress applications.
