Ahmed Sheets and Plates, based in Safat, Kuwait, has built a solid reputation as a reliable manufacturer and supplier of top-notch industrial metals, with a particular focus on Nickel Alloy 201 sheets and plates. Renowned for their precision engineering and careful selection of high-quality materials, the company strictly adheres to global standards, ensuring they provide dependable and long-lasting metal solutions across various industries. Their Nickel Alloy 201 sheets and plates are crafted to deliver outstanding corrosion resistance, thermal stability, and impressive mechanical performance. Thanks to their advanced manufacturing capabilities and thorough quality control processes, Ahmed Sheets and Plates consistently achieves product excellence, making them a go-to supplier for demanding industrial and engineering needs.
The Nickel Alloy 201 sheets and plates are made from commercially pure nickel, featuring an extremely low carbon content, along with small amounts of iron, manganese, and silicon. This unique composition significantly boosts corrosion resistance, particularly in reducing environments. On the mechanical side, Nickel Alloy 201 boasts excellent tensile strength, remarkable ductility, and exceptional toughness, even when exposed to high temperatures. The alloy maintains its structural integrity during thermal cycling and shows impressive resistance to caustic alkalis and chemical corrosion. Its high malleability and weldability make it perfect for various fabrication processes that require both strength and corrosion resistance.
| Grade | Nickel Alloy 201 | UNS N02201 |
| Standard | ASTM B162 / ASME SB162 |
| Size | 1000 mm x 2010 mm, 1220 mm x 2440 mm, 1500 mm x 3000 mm, 2010 mm x 2010 mm, 2010 mm x 4000 mm |
| Thickness | 0.1mm To 100 mm |
| Finish | Hot rolled plate (HR), Cold rolled sheet (CR), 2B, 2D, BA NO(8), SATIN (Met with Plastic Coated) |
| Form | Sheets, Plates, Plain Sheet, Shim Sheet, Strip, Flats |
| Hardness | Soft, Hard, Half Hard, Quarter Hard, Spring Hard etc. |
| Grade | C | Mn | Si | S | Cu | Fe | Ni |
| Nickel 201 | 0.02 max | 0.35 max | 0.35 max | 0.01 max | 0.25 max | 0.40 max | 99.0 min |
| Density | Melting Point | Tensile Strength | Yield Strength (0.2%Offset) | Elongation |
| 8.9 g/cm3 | 1446 °C (2635 °F) | Psi – 67000 , MPa – 462 | Psi – 21500 , MPa – 148 | 45 % |
| STANDARD | WERKSTOFF NR. | UNS | JIS | BS | GOST | AFNOR | EN |
| Nickel 201 | 2.4068 | N02201 | NW 2201 | NA 12 | НП-2 | – | LC-Ni 99 |
We provide products that come with both mill test certificates and third-party test certificates, ensuring the highest standards of quality and compliance.
Nickel Alloy 201 Sheets and Plates offer excellent corrosion resistance, particularly in acidic and alkaline environments. They are highly resistant to oxidation and possess superior thermal and electrical conductivity. These alloys are known for their excellent formability, allowing easy shaping and welding. With outstanding mechanical properties at high and low temperatures, Nickel Alloy 201 is ideal for chemical processing, heat exchangers, and electronics applications. It also provides strength and stability, making it suitable for harsh environments and high-stress applications.
|
Nickel 201 plate Stocked Sizes |
|
|---|---|
|
Size (in inches) |
Size (in mm) |
|
.134″ |
3.40 |
|
.125″ |
3.18 |
|
.187″ |
4.75 |
|
.156″ |
3.96 |
|
.312″ |
7.92 |
|
.250″ |
6.35 |
|
.500″ |
12.7 |
|
.375″ |
9.53 |
|
.600″ |
15.9 |
|
.875″ |
22.2 |
|
.750″ |
19.1 |
|
1″ |
25.4 |
|
3″ |
76.2 |
|
1.250″ |
31.8 |
|
1.125″ |
28.6 |
|
1.500″ |
38.1 |
|
2″ |
50.8 |
|
1.750″ |
44.5 |
|
2.500″ |
63.5 |
Nickel Alloy 201 sheets and plates find extensive use in industries that demand superior corrosion resistance and thermal stability. They are particularly well-suited for chemical processing equipment, evaporators, heat exchangers, and storage vessels that come into contact with caustic and alkaline substances. In the electronics sector, they are utilized for battery components, electrical connectors, and precision parts due to their excellent conductivity and stability. Moreover, they are also employed in food processing, marine environments, and aerospace applications where durability and resistance to harsh conditions are crucial. Their outstanding formability further enhances their versatility in various applications.
