Ahmed Sheets and Plates, located in Safat, Kuwait, is a well-respected manufacturer and supplier of top-notch Nickel Alloy 201 Coil. They provide dependable solutions for industries that demand exceptional purity and corrosion resistance. The company is dedicated to producing coils that boast excellent structural integrity, workability, and stability even at high temperatures. With state-of-the-art processing facilities and rigorous quality control measures, Ahmed Sheets and Plates guarantees that each coil adheres to international standards and meets customer expectations. Their Nickel Alloy 201 Coil is highly regarded for its consistent performance, making it ideal for critical applications in chemical processing, electronics, power generation, and engineering sectors. (100 words)
Nickel Alloy 201 Coil is made from commercially pure nickel with a very low carbon content, which ensures remarkable resistance to intergranular embrittlement at elevated temperatures. Its chemical makeup includes nickel, along with carefully controlled amounts of iron, copper, manganese, and trace elements to enhance stability. On the mechanical side, it offers excellent tensile strength, good ductility, and superior thermal and electrical conductivity. The alloy is known for its outstanding resistance to alkalis and corrosive environments, maintaining its performance even under fluctuating temperatures. Nickel Alloy 201 also displays good magnetic properties and formability, making it a great choice for demanding applications that require both purity and mechanical reliability. (90 words)
| Specification | ASTM B162 / ASME SB 162 |
|---|---|
| Thickness | Plate 0125″ to 5.00″ / Sheets 008″ to .0125″ |
| Sheet / Plates Width | 1000mm, 1219mm, 1500mm, 1800mm, 2000mm, 2500mm, 3000mm, 3500mm, etc |
| Sheet / Plates Length | 2000mm, 2440mm, 3000mm, 5800mm, 6000mm, etc |
| Sheets Hardness | Half Hard, Quarter Hard, Soft, Hard, Spring Hard |
| Plate / Sheets Size | 15NB to 150NB In |
| Tempers | Annealed, 1/4, 1/2 Hard, 3/4 Hard, Full Hard |
| Coils Thickness | 0.3 mm to 120 mm |
| Coils Length | AS PER CUSTOMER’S REQUIREMENT |
| Form | Sheets, Plates, Coils, Strips, Circle, Ring, Disc, Foils |
| Value Added Service | Cladding, Heat Treatment, Annealed, Pickling, Rolling, Cutting, Bending, Forging, Minor Fabrication Etc. |
| Grade | C | Mn | Si | S | Cu | Fe | Ni |
|---|---|---|---|---|---|---|---|
| Nickel 201 | 0.2 max | 0.35 max | 0.35 max | 0.01 max | 0.25 max | 0.40 max | 99.0 min |
| Grade | Density | Tensile Strength | Yield Strength (0.2%Offset) | Melting Point | Elongation |
|---|---|---|---|---|---|
| Nickel 201 | 8.9 g/cm3 | Psi – 67000 , MPa – 462 | Psi – 21500 , MPa – 148 | 1446 °C (2635 °F) | 45 % |
| STANDARD | UNS | WERKSTOFF NR. | EN | JIS | BS | GOST | AFNOR |
|---|---|---|---|---|---|---|---|
| Nickel 201 | N02201 | 2.4068 | LC Ni 99.2 | NW 2201 | NA 12 | НП-2 | – |
We provide products that come with both mill test certificates and third-party test certificates, ensuring the highest standards of quality and compliance.
| Steel Coil | Size (mm) | Weight per Coil (Kg) | Size(mm) | Weight per Coil (Kg) |
|---|---|---|---|---|
| Nickel Alloy 201 Coil | 4000 x 2000 x 2.0 | 136.0 | 3000 x 1500 x 5.0 | 191.0 |
| Nickel Alloy 201 Coil | 4000 x 2000 x 3.0 | 204.0 | 4000 x 2000 x 5.0 | 340.0 |
| Nickel Alloy 201 Coil | 2500 x 1250 x 4.0 | 106.0 | 2500 x 1250 x 6.0 | 159.0 |
| Nickel Alloy 201 Coil | 3000 x 1500 x 4.0 | 153.0 | 3000 x 1500 x 6.0 | 230.0 |
| Nickel Alloy 201 Coil | 4000 x 2000 x 4.0 | 272.0 | 4000 x 2000 x 6.0 | 408.0 |
| Nickel Alloy 201 Coil | 2500 x 1250 x 5.0 | 133.0 |
The Nickel Alloy 201 coil/slitting coil has many advantages, including exceptional corrosion resistance, especially in environmental and reducing acidic conditions. Its high nickel content provides durability and long-term performance in harsh environments, including chemical processing and marine environments. The alloy exhibits excellent weldability, formability and machinability, allowing easy manufacture in a variety of shapes and sizes. In addition, it provides strength and stability at elevated temperatures, as well as reliability under stress. Nickel Alloy 201 also provides excellent electrical and thermal conductivity, making it ideal for applications where these properties are important.
Nickel Alloy 201 Coil finds extensive use in industries that need high corrosion resistance, thermal stability, and chemical purity. It’s commonly found in chemical processing equipment like reactors, heat exchangers, and caustic handling systems due to its strong resistance to harsh alkalis. In the electrical and electronics field, it’s utilized for lead wires, battery components, sensors, and precision electrical parts.
