Ahmed Sheets and Plates is a renowned manufacturer and supplier in Safat, Kuwait, offering a high-performance version of Inconel 600 Channels that can be used continuously at extreme temperatures and in corrosive environments. These channels exhibit superior strength, resistance to oxidation, and metallurgical stability, finding extensive applications in those areas where outstanding reliability is required. Manufactured with advanced production techniques, Ahmed Sheets and Plates guarantees precision, durability, and adherence to international quality standards. Inconel 600 Channels from Ahmed Sheets and Plates serve chemical processing, power generation, and heat-treatment applications with long service life even under severe operational conditions. The customers believe in the company for consistent quality and reliable nickel-based alloy solutions.
Inconel 600 Channels are made basically of nickel, chromium, and iron, offering a good balance of corrosion resistance and high-temperature strength. The chemical composition of the alloy includes about 72% nickel, 14–17% chromium, and 6–10% iron, with smaller quantities of carbon, manganese, and silicon. These channels possess very good mechanical properties such as high tensile strength, exceptionally good creep resistance, and stability over a wide range of temperatures. For this reason, their excellent oxidation behavior and non-magnetic properties can be employed under severe conditions. Inconel 600 Channels can resist thermal shock, pressure, and corrosion to protect the structural integrity of the material for reliable performance over an extended period of time.
Specifications : ASTM B166 / ASME SB166
Angle Size Range : 20 x 20 mm to 100 x 100 mm
Angles Thickness : 3 to 12 mm (depending on size)
Channel Size Range : Base: 80 to 150 mm; Side: 40 to 75 mm
Channel Thickness : 5 to 6 mm (depending on size)
Length : 3MTR, 4MTR, 5MTR, 6MTR, or Custom Cut Sizes
| Grade | UNS | DIN | JIS | BS | GOST | AFNOR | EN |
| Alloy 600 | N06600 | 2.4816 | NCF 600 | NA 13 | МНЖМц 28-2,5-1,5 | NC15FE11M | NiCr15Fe |
| Grade | C | Mn | Si | S | Cu | Fe | Ni | Cr |
| Alloy 600 | 0.15 max | 1.00 max | 0.50 max | 0.015 max | 0.50 max | 6.00 – 10.00 | 72.00 min | 14.00 – 17.00 |
| Element | Density | Melting Point | Tensile Strengt | Yield Strength (0.2%Offset) | Elongation |
| Alloy 600 | 8.47 g/cm3 | 1413 °C (2580 °F) | Psi – 95,000 , MPa – 655 | Psi – 45,000 , MPa – 310 | 40 % |
We provide products that come with both mill test certificates and third-party test certificates, ensuring the highest standards of quality and compliance.
Ahmed Sheets and Plates based in Safat, Kuwait, is a leading supplier and stockist of high-quality metal products, including sheets, plates, coils, foils, angles, channels, circles, and slitting coils, all offered with exceptional service and tailored to meet our customers specific requirements. With a focus on delivering superior products, we cater to a wide range of industries, providing reliable solutions for diverse applications. Our extensive inventory includes Known for our unique finishing techniques and commitment to quality. We are dedicated to ensuring customer satisfaction through dependable service and top-notch products.
Inconel 600 Channel offers numerous advantages, making it highly sought after in demanding industries. Its exceptional resistance to oxidation and corrosion ensures durability in high-temperature and chemically aggressive environments. The alloy maintains strength and structural integrity under extreme thermal conditions, offering excellent creep-rupture properties. Its versatility allows it to perform effectively in a wide range of applications, including chemical processing, aerospace, and marine industries. Additionally, Inconel 600 resists stress-corrosion cracking and chloride-ion-induced pitting, ensuring long-term performance in challenging environments, thus reducing maintenance and replacement costs.
| Sizes (all Dimensions in milimeter) | Approx Weight Inconel Angle Bar (kilogram/meter) | Inconel Angle Bar Sizes (all Dimensions in milimeter) | Approx Weight Inconel Angle Bar (kilogram/meter) |
|---|---|---|---|
| 25 x 25 x 3 | 1.13 | 63 x 63 x 8 | 7.50 |
| 25 x 25 x 4 | 1.46 | 65 x 65 x 4 | 4.00 |
| 25 x 25 x 5 | 1.78 | 65 x 65x 5 | 5.02 |
| 30 x 30 x 3 | 1.37 | 65 x 65 x 8 | 7.75 |
| 30 x 30 x 4 | 1.78 | 70 x 70 x 5 | 5.35 |
| 30 x 30 x 5 | 2.20 | 70 x 70 x 6 | 6.40 |
| 40 x 40 x 3 | 1.83 | 75 x 75 x 6 | 6.85 |
| 40 x 40 x 4 | 2.41 | 75 x 75 x 8 | 9.05 |
| 40 x 40 x 5 | 2.97 | 80 x 80 x 6 | 7.35 |
| 50 x 50 x 4 | 3.05 | 80 x 80 x 8 | 9.65 |
| 50 x 50 x 5 | 3.78 | 80 x 80 x 10 | 11.98 |
| 63 x 63 x 4 | 3.90 | 100 x 100 x 8 | 12.20 |
| 63 x 63 x 5 | 3.90 | 100 x 100 x 12 | 18.00 |
| Size in Inches | Est. Weight per Ft. Lbs. | Est. Weight per 20′ Bar |
|---|---|---|
| 3/4 x 3/4 x 1/8 | 0.59 | 11.80 |
| 1 x 1 x 1/8 | 0.80 | 16.00 |
| 1 x 1 x 3/16 | 1.16 | 23.20 |
| 1 x 1 x 1/4 | 1.49 | 29.80 |
| 1-1/4 x 1-1/4 x 1/8 | 1.01 | 20.20 |
| 1-1/4 x 1-1/4 x 3/16 | 1.48 | 29.60 |
| 1-1/4 x 1-1/4 x 1/4 | 1.92 | 38.40 |
| 1-1/2 x 1-1/2 x 1/8 | 1.23 | 24.60 |
| 1-1/2 x 1-1/2 x 3/16 | 1.80 | 36.00 |
| 1-1/2 x 1-1/2 x 1/4 | 2.34 | 46.80 |
| 2 x 2 x 1/8 | 1.65 | 33.00 |
| 2 x 2 x 3/16 | 2.44 | 48.80 |
| 2 x 2 x 1/4 | 3.19 | 63.80 |
| 2 x 2 x 3/8 | 4.70 | 94.00 |
| 2-1/2 x 2-1/2 x 3/16 | 3.07 | 61.40 |
| 2-1/2 x 2-1/2 x 1/4 | 4.10 | 82.00 |
| 3 x 3 x 1/4 | 4.90 | 98.00 |
| 4 x 4 x 1/4 | 6.60 | 132.00 |
| 4 x 4 x 3/8 | 9.80 | 196.00 |
Yes, we offer custom sizes for Inconel 600 Channel to meet specific project needs. Our team at Ahmed Sheets and Plates is dedicated to providing tailored solutions for all your requirements. For more details, contact us at sales@aaronsheetsplates.com.
Inconel 600 Channels are widely used in heat, corrosion, and chemical exposure applications. They find wide application in furnace parts, heat-treating equipment, chemical processing equipment, and power generating plants. Their resistance to high-temperature oxidation makes them suitable for catalytic reactors, boiler components, and the parts of aerospace engines. These channels also find usage in food processing, nuclear engineering, and marine applications due to their resistance to chloride-induced stress-corrosion. Inconel 600 Channels can be relied upon in industries for the fabrication of structural supports, frames, and high-strength assemblies that need to retain their performance under continuous thermal and mechanical stresses.
