Ahmed Sheets and Plates, based in Safat, Kuwait, stands out as a top-notch manufacturer and supplier of high-quality industrial metals, with a focus on Incoloy 800, 800H, and 800HT channels. Known for their precision engineering and unwavering quality standards, this company delivers durable and dependable metal solutions for a variety of industrial needs. Their Incoloy channels are crafted to meet international standards, providing remarkable resistance to oxidation, corrosion, and high temperatures. Thanks to advanced production methods and strict quality control, Ahmed Sheets and Plates guarantees that each channel offers exceptional strength, dimensional stability, and long-lasting performance, making them perfect for demanding applications in the chemical, power, and engineering sectors.
Incoloy 800, 800H, and 800HT are nickel-iron-chromium alloys, carefully formulated with specific amounts of carbon, manganese, and silicon to boost strength and oxidation resistance. These channels showcase impressive tensile and yield strength, outstanding creep resistance, and remarkable toughness at both room and elevated temperatures. Incoloy 800H is known for its higher creep rupture strength, while 800HT excels in high-temperature strength and stability. The alloys maintain their shape under thermal stress and resist corrosion in both oxidizing and mildly reducing environments. Their blend of strength, durability, and high-temperature performance makes them ideal for critical industrial applications that demand reliability and a long service life.
Specifications : ASTM B408 / ASME SB408
Angle Size Range : 20 x 20 mm to 100 x 100 mm
Angles Thickness : 3 to 12 mm (depending on size)
Channel Size Range : Base: 80 to 150 mm; Side: 40 to 75 mm
Channel Thickness : 5 to 6 mm (depending on size)
Length : 3MTR, 4MTR, 5MTR, 6MTR, or Custom Cut Sizes
| STANDARD | WERKSTOFF NR. | UNS | JIS | BS | GOST | AFNOR | EN | OR |
| Incoloy 800 | 1.4876 | N08800 | NCF 800 | NA 15 | ЭИ670 | Z8NC32-21 | X10NiCrAlTi32-20 | XH32 |
| Incoloy 800H | 1.4958 / 1.4876 | N08810 | NCF 800H | NA 15(H) | ЭИ670 | Z8NC33-21 | X5NiCrAlTi31-20 | XH32T |
| Incoloy 800HT | 1.4859 / 1.4876 | N08811 | NCF 800HT | NA 15(HT) | ЭИ670 | – | X8NiCrAlTi32-21 | XH32T |
| Grade | C | Mn | Si | S | Cu | Fe | Ni | Cr | Al | Ti |
| Incoloy 800 | 0.10 max | 1.50 max | 1.00 max | 0.015max | 0.75 max | 39.50 min | 30.00 – 35.00 | 19.00 – 23.00 | 0.15 – 0.60 | 0.15 – 0.60 |
| Incoloy 800H | 0.05 – 0.10 | 1.50 max | 1.00 max | 0.015 max | 0.75 max | 39.50 min | 30.00 – 35.00 | 19.00 – 23.00 | 0.15 – 0.60 | 0.15 – 0.60 |
| Incoloy 800HT | 0.06 – 0.10 | 1.50 max | 1.00 max | 0.015 max | 0.75 max | 39.50 min | 30.00 – 35.00 | 19.00 – 23.00 | 0.15 – 0.60 | 0.15 – 0.60 |
| Element | Density | Melting Point | Tensile Strength | Yield Strength (0.2%Offset) | Elongation |
| Incoloy 800 / 800H / 800HT | 7.94 g/cm3 | 1385 °C (2525 °F) | Psi – 75,000 , MPa – 520 | Psi – 30,000 , MPa – 205 | 30 % |
We provide products that come with both mill test certificates and third-party test certificates, ensuring the highest standards of quality and compliance.
Ahmed Sheets and Plates based in Safat, Kuwait, is a leading supplier and stockist of high-quality metal products, including Sheets, Plates, Coils, Foils, Angles, Channels, Circles, and Slitting Coils, all offered with exceptional service and tailored to meet our customers specific requirements. With a focus on delivering superior products, we cater to a wide range of industries, providing reliable solutions for diverse applications. Our extensive inventory includes Known for our unique finishing techniques and commitment to quality. We are dedicated to ensuring customer satisfaction through dependable service and top-notch products.
Incoloy 800, 800H, and 800HT channels offer several advantages, including exceptional resistance to oxidation, carburization, and thermal degradation at high temperatures. These alloys maintain strength and stability in extreme environments, making them ideal for applications in chemical processing, power plants, and heat exchangers. Incoloy 800H and 800HT variants provide enhanced creep strength and resistance to thermal fatigue, with 800HT offering superior stability at elevated temperatures. Additionally, these alloys exhibit excellent weldability, formability, and corrosion resistance, ensuring long-term reliability and durability in challenging industrial conditions.
Yes, we offer custom sizes for Incoloy 800 / 800H / 800HT Channel to meet specific project needs. Our team at Ahmed Sheets and Plates is dedicated to providing tailored solutions for all your requirements. For more details, contact us at sales@aaronsheetsplates.com.
Incoloy 800, 800H, and 800HT channels find extensive use in the chemical processing, petrochemical, and power generation industries, where high-temperature resistance is crucial. They are perfect for heat exchangers, furnace components, boilers, and structural frameworks that face oxidizing and corrosive conditions. Additionally, these channels are utilized in petrochemical piping systems, nuclear reactors, and industrial machinery, offering excellent stability and durability even in extreme environments.
