Ahmed Sheets and Plates, based in Safat, Kuwait, stands out as a top manufacturer and supplier of high-quality Aluminium 5005 Plates and Sheets. These products are designed to offer outstanding corrosion resistance, durability, and a lightweight feel. With precision rolling and finishing, they ensure a consistent thickness and a smooth surface that meets international standards. Aluminium 5005 is particularly resistant to both atmospheric and marine corrosion, making it a fantastic choice for a variety of applications in architecture, construction, and industry. Ahmed Sheets and Plates is committed to delivering reliable products that blend strength, formability, and long-lasting performance, making these plates and sheets perfect for roofing, cladding, decorative panels, transportation, and a range of engineering and fabrication projects.
Aluminium 5005 Plates and Sheets are made primarily from aluminium alloyed with magnesium and small amounts of chromium, which boosts their corrosion resistance, strength, and formability. This alloy showcases moderate tensile and yield strength, along with excellent ductility and top-notch resistance to atmospheric and marine corrosion. Aluminium 5005 is also easy to work with and weld, allowing for bending, shaping, and crafting into intricate designs. Despite being lightweight, it remains durable and stable under typical mechanical loads. These mechanical properties make it a go-to choice for architectural, marine, and industrial applications where corrosion resistance, moderate strength, and long-term reliability are key.
| Standards | ASTM B209 / ASME SB209 |
| Temper | O,H12,H14,H16,H18,H19,H22,H24 |
| Thickness | 0.2-50 |
| Width | 100-2600 |
| Length | 500-10000 |
| Surface | Bright, polished, hair line, brush, sand blast, embossed, etching, etc. |
| Finish | Mill, Customer specific finish |
| Aluminum Sheet/ Plate Coating | PVC Coated, Color Coated, Polyester, Fluorocarbon, polyurethane and epoxy coating |
| Type | Hot-Rolled (HR) / Cold-Rolled (CR) Sheet |
| Chemical Properties | % Value |
| Silicon (Si) | 0.30 |
| Chromium (Cr) | 0.10 |
| Manganese (Mn) | 0.20 |
| Magnesium (Mg) | 0.5-1.1 |
| Copper (Cu) | 0.20 |
| Titanium (Ti) | – |
| Iron (Fe) | 0.7 |
| Zinc (Zn) | 0.25 |
| Aluminium (Al) | Balance |
| Property | Value |
| Proof Stress | 120 Min MPa |
| Tensile Strength | 145 – 185 MPa |
| Elongation at 50 mm | 3 Min % |
| Hardness Brinell | 47 HB |
We provide products that come with both mill test certificates and third-party test certificates, ensuring the highest standards of quality and compliance.
Aluminium 5005 Sheets and Plates offer numerous advantages, including excellent corrosion resistance, making them suitable for marine and outdoor environments. They have superior anodizing qualities, ensuring an attractive, durable finish ideal for architectural applications. Their lightweight nature allows for easy handling and fabrication, reducing transportation and installation costs. Aluminium 5005 demonstrates good weldability and moderate strength, providing versatility across various industries. Its non-heat-treatable but cold-workable property enhances strength when needed, making it a reliable choice for roofing, cladding, signage, and decorative applications where durability and aesthetics are key.
Yes, we offer custom sizes for Aluminium 5005 Plates and Sheets to meet specific project needs. Our team at Ahmed Sheets and Plates is dedicated to providing tailored solutions for all your requirements. For more details, contact us at sales@aaronsheetsplates.com.
| Standard | UNS | ISO | BS | DIN |
| 5005 | A95005 | AlMg1 | N41 | 3.3315 |
| Properties | Metric | Imperial |
| Tensile strength | 130 MPa | 18855 psi |
| Yield strength | 125 MPa | 18130 psi |
| Shear strength | 83 MPa | 12039 psi |
| Fatigue strength | 55 MPa | 7977 psi |
| Elastic modulus | 70-80 GPa | 10153-11603 ksi |
| Poisson’s ratio | 0.33 | 0.33 |
| Elongation | 10% | 10% |
| Hardness | 35 | 35 |
Aluminium 5005 Plates and Sheets find extensive use across construction, architecture, transportation, and industrial sectors, thanks to their lightweight nature, corrosion resistance, and moderate strength. In the realms of construction and architecture, they are often utilized for roofing, cladding, and decorative panels, while in transportation, they serve in various applications where durability and weight savings are crucial. Additionally, their versatility makes them suitable for a wide range of general-purpose engineering and fabrication projects, ensuring they meet the diverse needs of different industries.
